| Abmessungen mm |
Gewicht warmgefertigt kg/m |
Gewicht kaltgefertigt kg/m |
|---|---|---|
| 200 x 40 x 3,0 | - | 10,84 |
| 200 x 40 x 4,0 | - | 14,25 |
| 200 x 40 x 5,0 | - | 17,55 |
| 200 x 40 x 5,6 | - | 19,30 |
| 200 x 40 x 6,0 | - | 20,75 |
| 200 x 40 x 6,3 | - | 21,42 |
| 200 x 40 x 7,1 | - | 23,81 |
| 200 x 40 x 8,0 | - | 26,41 |
| 200 x 80 x 3,0 | - | 12,70 |
| 200 x 80 x 4,0 | - | 16,76 |
| 200 x 80 x 5,0 | - | 20,69 |
| 200 x 80 x 5,6 | - | 22,80 |
| 00 x 80 x 6,0 | - | 24,52 |
| 200 x 80 x 6,3 | - | 25,37 |
| 200 x 80 x 7,1 | - | 28,27 |
| 200 x 80 x 8,0 | - | 31,34 |
| 200 x 100 x 3,0 | - | 13,70 |
| 200 x 100 x 4,0 | - | 18,00 |
| 200 x 100 x 5,0 | 22,70 | 22,10 |
| 00 x 100 x 5,6 | 25,10 | 24,50 |
| 200 x 100 x 6,0 | - | 26,40 |
| 200 x 100 x 6,3 | 28,10 | 27,40 |
| 200 x 100 x 7,1 | 31,40 | 30,50 |
| 200 x 100 x 8,0 | 35,10 | 33,90 |
| 200 x 100 x 8,8 | 38,40 | 36,93 |
| 200 x 100 x 10,0 | 43,10 | 41,30 |
| 200 x 100 x 11,0 | 47,00 | - |
| 200 x 100 x 12,5 | 52,70 | - |
| 200 x 100 x 14,2 | 58,90 | - |
| 200 x 100 x 16,0 | 65,20 | - |
| 200 x 120 x 3,0 | - | 14,60 |
| 200 x 120 x 4,0 | - | 19,30 |
| 200 x 120 x 5,0 | - | 23,80 |
| 200 x 120 x 5,6 | 26,50 | 26,30 |
| 200 x 120 x 6,0 | - | 28,30 |
| 200 x 120 x 6,3 | 30,10 | 29,30 |
| 200 x 120 x 7,1 | 33,70 | 32,70 |
| 200 x 120 x 8,0 | 37,60 | 36,50 |
| 200 x 120 x 8,8 | 41,10 | 39,69 |
| 200 x 120 x 10,0 | 46,30 | 44,40 |
| 200 x 120 x 11,0 | 50,40 | - |
| 200 x 120 x 12,5 | 56,60 | - |
| 200 x 120 x 14,2 | 63,30 | - |
| 200 x 120 x 16,0 | 70,20 | - |
| 200 x 150 x 4,0 | - | 21,20 |
| 200 x 150 x 5,0 | - | 26,18 |
| 200 x 150 x 5,6 | - | 28,90 |
| 200 x 150 x 6,0 | - | 31,11 |
| 200 x 150 x 6,3 | - | 32,30 |
| 200 x 150 x 7,1 | - | 36,07 |
| 200 x 150 x 8,0 | - | 40,23 |
| 200 x 150 x 10,0 | - | 49,11 |
| 220 x 120 x 6,0 | - | 30,20 |
| 220 x 120 x 6,3 | 32,00 | 31,31 |
| 220 x 120 x 7,1 | 35,90 | 34,50 |
| 220 x 120 x 8,0 | 40,20 | 38,97 |
| 220 x 120 x 8,8 | 43,90 | 41,93 |
| 220 x 120 x 10,0 | 49,40 | - |
| 220 x 120 x 11,0 | 53,90 | - |
| 220 x 120 x 12,5 | 60,50 | - |
| 220 x 120 x 14,2 | 67,80 | - |
| 220 x 120 x 16,0 | 75,20 | - |
